Intel 7th Gen. Core i7/i5/i3 Processor
Max: 150W
Q170
2 x 260-pin DDR4 SO-DIMM memory, up to 32GB
-
1 x Line out, 1 x Mic-in
-
1 x 8-bit GPIO, terminal block
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x power button
1 x RS-232/422/485, DB9 (default RS-232)
1 x RS-232 DB9
1 x RS-422/485, DB9 ( default RS-485, optional)
1 x RS-232 DB9 (optional)
4 x USB 3.0 type A
2 x USB 2.0 type A
2 x 2.5” SATA3 HDD/SSD, Easy-swappable HDD tray
-
-
2 x full-size Mini-PCIe slot
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
232 x 190 x 67 mm
Wall Mount (default) & Din Rail (optional)
3.3 kg
Meet CE/FCC Class A
-20˚C~60˚C(for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90% @ 40°C, non- condensing
-40~85 °C
Win10 IoT, Linux Kernel 4.15 (Ubuntu 16.04.4)
-
Intel 7th Gen. Core i7/i5/i3 Processor
Max: 150W
Q170
2 x 260-pin DDR4 SO-DIMM memory, up to 32GB
-
1 x Line out, 1 x Mic-in
-
1 x 8-bit GPIO, terminal block
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x power button
1 x RS-232/422/485, DB9 (default RS-232)
1 x RS-232 DB9
1 x RS-422/485, DB9 ( default RS-485, optional)
1 x RS-232 DB9 (optional)
4 x USB 3.0, type A
2 x USB 2.0, type A
2 x 2.5” SATA3 HDD/SSD, Easy-swappable HDD tray
-
Expansion Slot : 1 x PCIe-16, 1 x PCIe-4, default
1 x PCIe-16, 1 x PCI, optional
2 x full-size Mini-PCIe slot
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 190 x 117 mm
Wall Mount (default) & Din Rail (optional)
4.1 kg
Meet CE/FCC Class A
-20˚C~60˚C(for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90% @ 40°C, non- condensing
-40~85 °C
Win10 IoT, Linux Kernel 4.15 (Ubuntu 16.04.4)
-
Intel 7th Gen. Core i7/i5/i3 Processor
Max: 150W
Q170
2 x 260-pin DDR4 SO-DIMM memory, up to 32GB
-
1 x Line out, 1 x Mic-in
-
1 x 8-bit GPIO, terminal block
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x power button
1 x RS-232/422/485, DB9 (default RS-232)
1 x RS-232 DB9
1 x RS-422/485, DB9 ( default RS-485, optional)
1 x RS-232 DB9 (optional)
4 x USB 3.0, type A
2 x USB 2.0, type A
2 x 2.5” SATA3 HDD/SSD, Easy-swappable HDD tray
-
Expansion Slot : 1 x PCIe-16, 1 x PCIe-4, 1 x PCIe-1, default
4 x PCI, optional
2 x full-size Mini-PCIe slot
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 190 x 157 mm
Wall Mount (default) & Din Rail (optional)
4.4 Kg
Meet CE/FCC Class A
-20˚C~60˚C(for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90% @ 40°C, non- condensing
-40~85 °C
Win10 IoT, Linux Kernel 4.15 (Ubuntu 16.04.4)
-
Intel 9th Gen. Core i7/i5/i3 Processor
Max: 150W
Q370
2 x 260-pin DDR4 SO-DIMM memory, up to 64GB
-
-
-
-
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x Power button with light
1 x RS-232/422/485 DB-9 (COM1, default RS-232)
1 x RS-232 DB-9 (COM2)
4 x USB 3.2 Gen1 type A
1 x internal USB2.0 Type A for dongle
2 x 2.5” SATA3 HDD/SSD , Easy-swappable HDD tray
-
-
1 x Full size Mini-PCIe slot
1 x M.2 M key 2280/2242 support NVMe
PCIe x4 supporting NVMe
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 190 x 77 mm
Wall Mount (default) & Din Rail (option)
3.4Kg
Meet CE/FCC Class A
-20˚C~60˚C(for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Win10 IoT, Windows 11, Linux Kernel 4.15 (Ubuntu 16.04.4)
-
Intel 9th Gen. Core i7/i5/i3 Processor
Max: 180W
Q370
2 x 260-pin DDR4 SO-DIMM memory, up to 64GB
-
-
-
-
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x Power button with light
1 x RS-232/422/485 DB-9 (COM1, default RS-232)
1 x RS-232 DB-9 (COM2)
4 x USB 3.2 Gen1 type A
1 x internal USB2.0 Type A for dongle
2 x 2.5” SATA3 HDD/SSD , Easy-swappable HDD tray
HS (High Speed) expansion I/O:
2 x GbE LAN, RJ-45 by intel I210(I211) AT
2 x USB 3.0, type A
1 x 8bit GPIO, terminal block 1x10 pin
-
1 x Full size Mini-PCIe slot
1 x M.2 M key 2280/2242 support NVMe
Plating Titanium Gray Aluminum Heat sink and Black Steel Chassis
222 x 190 x 77 mm
Wall Mount (default) & Din Rail (option)
3.4Kg
Meet CE/FCC Class A
-20˚C~60˚C(for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Win10 IoT, Windows 11, Linux Kernel 4.15 (Ubuntu 16.04.4)
-
Intel 9th Gen. Core i7/i5/i3 Processor
Max: 150W
Q370
2 x 260-pin DDR4 SO-DIMM memory, up to 64GB
-
-
-
-
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x Power button with light
1 x RS-232/422/485 DB-9 (COM1, default RS-232)
1 x RS-232 DB-9 (COM2)
4 x USB 3.2 Gen1 type A
1 x internal USB2.0 Type A for dongle
2 x 2.5” SATA3 HDD/SSD, Easy-swappable HDD tray
-
Expansion Slot : 1 x PCIe-16, 1 x PCIe-4, default
1 x Full size Mini-PCIe slot
1 x M.2 M key 2280/2242 support NVMe
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 190 x 127 mm
Wall Mount (default) & Din Rail (option)
4.2 kg
Meet CE/FCC Class A
-20˚C~60˚C (for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Win10 IoT, Windows 11, Linux Kernel 4.15 (Ubuntu 16.04.4)
-
Intel 9th Gen. Core i7/i5/i3 Processor
Max: 150W
Q370
2 x 260-pin DDR4 SO-DIMM memory, up to 64GB
-
-
-
-
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x Power button with light
1 x RS-232/422/485 DB-9 (COM1, default RS-232)
1 x RS-232 DB-9 (COM2)
4 x USB 3.2 Gen1 type A
1 x internal USB2.0 Type A for dongle
2 x 2.5” SATA3 HDD/SSD, Easy-swappable HDD tray
HS (High Speed) expansion I/O:
2 x GbE LAN, RJ-45 by intel I210(I211) AT
2 x USB 3.0, type A
1 x 8bit GPIO, terminal block
Expansion Slot : 1 x PCIe-16, 1 x PCIe-4, default
1 x Full size Mini-PCIe slot
1 x M.2 M key 2280/2242 support NVMe
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 190 x 127mm
Wall Mount (default) & Din Rail (option)
4.2 kg
Meet CE/FCC Class A
-20˚C~60˚C (for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Win10 IoT, Windows 11, Linux Kernel 4.15 (Ubuntu 16.04.4)
-
Intel 9th Gen. Core i7/i5/i3 Processor
Max: 150W
Q370
2 x 260-pin DDR4 SO-DIMM memory, up to 64GB
-
-
-
-
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x Power button with light
1 x RS-232/422/485 DB-9 (COM1, default RS-232)
1 x RS-232 DB-9 (COM2)
4 x USB 3.2 Gen1 type A
1 x internal USB2.0 Type A for dongle
2 x 2.5” SATA3 HDD/SSD, Easy-swappable HDD tray
-
Expansion Slot : 1 x PCIe-16, 2 x PCIe-4, default
1 x Full size Mini-PCIe slot
1 x M.2 M key 2280/2242 support NVMe
PCIe x4 supporting NVMe
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 190 x 176 mm
Wall Mount (default) & Din Rail (option)
4.5Kg
Meet CE/FCC Class A
-20˚C~60˚C (for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Win10 IoT, Windows 11, Linux Kernel 4.15 ( Ubuntu 16.04.4 )
-
Intel 9th Gen. Core i7/i5/i3 Processor
Max: 150W
Q370
2 x 260-pin DDR4 SO-DIMM memory, up to 64GB
-
-
-
-
-
1 x VGA
1 x HDMI
-
2 x GbE LAN RJ-45
-
1 x 3-pin DC power input terminal block
1 x 2-pin power switch
1 x Power button with light
1 x RS-232/422/485 DB-9 (COM1, default RS-232)
1 x RS-232 DB-9 (COM2)
4 x USB 3.2 Gen1 type A
1 x internal USB2.0 Type A for dongle
2 x 2.5” SATA3 HDD/SSD, Easy-swappable HDD tray
HS (High Speed) expansion I/O:
2 x GbE LAN, RJ-45 by intel I210(I211) AT
2 x USB 3.2 Gen1 type A
1 x 8bit GPIO, terminal block
Expansion Slot : 1 x PCIe-16, 2 x PCIe-4, default
1 x Full size Mini-PCIe slot
1 x M.2 M key 2280/2242 support NVMe
PCIe x4 supporting NVMe
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 190 x 176 mm
Wall Mount (default) & Din Rail (option)
4.5Kg
Meet CE/FCC Class A
-20˚C~60˚C (for i3/i5 model)
-20˚C~50˚C (for i7 model)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Win10 IoT, Windows 11, Linux Kernel 4.15 ( Ubuntu 16.04.4 )
AMI
Intel 13th Gen. Core i9/i7/i5/i3, up to 65W
Intel 12th Gen. Core i9/i7/i5/i3, up to 65W
-
Intel Q670E
2 x 262-pin DDR5 (4800MHz) SO-DIMM Memory, up to 32GB (16GB per slot)
TPM 2.0
1 x Line-out 3.5mm Phone Jack
1 x Mic-in 3.5mm Phone Jack
1 x Power Button with LED
-
1 x DP++ 1.4A, up to 7680 x 4320 @60Hz
-
1 x HDMI 2.0a, up to 4096 x 2160 @60Hz
2 x 2.5GbE LAN RJ-45 (i226LM, LAN1 Support iAMT)
LED Indicators: 1 x M.2 SSD / 1 x 2.5" SATA
1 x 3-pin DC Power Input via Terminal Block
4 x RS-232/422/485 Selectable Default RS-232
4 x USB 3.2 Gen1 Type-A
Default: 1 x M.2 M-key, 2280/2242 (SATA3, PCIe 4.0 x4) for SSD
Option: 2 x 2.5” SATA3 HDD/SSD (Easy-swappable HDD tray), with RAID 0,1
Optional High Speed Expansion I/O:
2 x USB 3.2 Gen1 Type-A
2 x GbE LAN RJ-45 (i210AT/i211AT (from TB-619))
8 x Digital I/O Terminal Block 1x10-pin, 4 x SI, 4 x SO
-
1 x M.2 E-key, 2230 for Wi-Fi / Bluetooth
1 x M.2 B-key, 3042/3052 (PCIe 3.0 x1, USB 3.2 Gen.1/ USB2.0) for optional 4G/5G module
1 x NANO SIM slot
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 217 x 95
Wall Mount (default) & DIN Rail Back Side (optional)
3.9 kg
Meet CE / FCC Class A
-20~60˚C (for 35W CPU)
-20~50˚C (for 65W CPU),
ambient with air flow (with industrial storage)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Windows 10 IoT LTSC / Windows 11 IoT / Ubuntu 22.04 (Linux Kernel 5.15)
AVS-530:
Fanless Box PC, 12th/13th Gen. Intel Core i3/i5/i7/i9, 2 x DDR5 SO-DIMM slots, 1 x M.2 2280/2242 M-key slot, 2 x 2.5" SSD trays, 4 x COM, 2 x 2.5GbE LAN, 4 x USB 3.2, 1 x DP 1.4A, 1 x HDMI 2.0a, 1 x Line-out, 1 x Mic-in, 1 x M.2 2230 E-Key, 1 x M.2 3042/3052 B-key , 9~32V DC power input w/o adaptor
AVS-530QL:
Fanless Box PC, 12th/13th Gen. Intel Core i3/i5/i7/i9, 2 x DDR5 SO-DIMM slots, 1 x M.2 2280/2242 M-key slot, 2 x 2.5" SSD trays, 4 x COM, 2 x 2.5GbE LAN, 6 x USB 3.2, 1 x DP 1.4A, 1 x HDMI 2.0a, 1 x Line-out, 1 x Mic-in,1 x M.2 2230 E-Key, 1 x M.2 3042/3052 B-key, 2 x GbE LAN, 8-bit DIO, 9~32V DC power input w/o adaptor
Others:
Watchdog Timer (256 steps)
6 x SMA for Wi-Fi and 4G LTE/ 5G/ GPS Antennas
AMI
Intel 13th Gen. Core i9/i7/i5/i3, up to 65W
Intel 12th Gen. Core i9/i7/i5/i3, up to 65W
-
Intel Q670E
2 x 262-pin DDR5 (4800MHz) SO-DIMM Memory, up to 32GB (16GB per slot)
TPM 2.0
1 x Line-out 3.5mm Phone Jack
1 x Mic-in 3.5mm Phone Jack
1 x Power Button with LED
-
1 x DP++ 1.4A, up to 7680 x 4320 @60Hz
-
1 x HDMI 2.0a, up to 4096 x 2160 @60Hz
2 x 2.5GbE LAN RJ-45 (i226LM, LAN1 Support iAMT)
LED Indicators: 1 x M.2 SSD / 1 x 2.5" SATA
1 x 3-pin DC Power Input via Terminal Block
4 x RS-232/422/485 Selectable Default RS-232
4 x USB 3.2 Gen1 Type-A
Default: 1 x M.2 M-key, 2280/2242 (SATA3, PCIe 4.0 x4) for SSD
Option: 2 x 2.5” SATA3 HDD/SSD (Easy-swappable HDD tray), with RAID 0,1
Optional High Speed Expansion I/O:
2 x USB 3.2 Gen1 Type-A
2 x GbE LAN RJ-45 (i210AT/i211AT (from TB-619))
8 x Digital I/O Terminal Block 1x10-pin, 4 x SI, 4 x SO
Expansion Slot : 1 x PCIe x16 + 1 x PCIe x4 (FAN optional)
Note: PCIe Board (include GPU card)
Dimension: L ≦ 195mm, H < 45mm, W ≦ 120mm
1 x M.2 E-key, 2230 for Wi-Fi / Bluetooth
1 x M.2 B-key, 3042/3052 (PCIe 3.0 x1, USB 3.2 Gen.1/ USB2.0) for optional 4G/5G module
1 x NANO SIM slot
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 217 x 145
Wall Mount (default) & DIN Rail Back Side (optional)
4.5 kg
Meet CE / FCC Class A
-20~60˚C (for 35W CPU)
-20~50˚C (for 65W CPU),
ambient with air flow (with industrial storage)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Windows 10 IoT LTSC / Windows 11 IoT / Ubuntu 22.04 (Linux Kernel 5.15)
AVS-532:
Fanless Box PC, 12/13th Gen. Intel Core i3/i5/i7/i9, 2 x DDR5 SO-DIMM slots, 1 x M.2 2280/2242 M-key slot, 2 x 2.5" SSD trays, 4 x COM, 2 x 2.5GbE LAN, 4 x USB 3.2, 1 x DP 1.4A, 1 x HDMI 2.0a, 1 x Line-out, 1 x Mic-in, 1x M.2 2230 E-Key, 1 x M.2 3042/3052 B-key, 1 x PCIe Gen.4 x16 + 1 x PCIe Gen.3 x4 with FAN, 9~32V DC power input w/o adaptor
AVS-532QL:
Fanless Box PC, 12/13th Gen. Intel Core i3/i5/i7/i9, 2 x DDR5 SO-DIMM slots, 1 x M.2 2280/2242 M-key slot, 2 x 2.5" SSD trays, 4 x COM, 2 x 2.5GbE LAN, 6 x USB 3.2, 1 x DP 1.4A, 1 x HDMI 2.0a, 1 x Line-out, 1 x Mic-in, 1x M.2 2230 E-Key, 1 x M.2 3042/3052 B-key, 2 x GbE LAN, 8-bit DIO, 1 x PCIe Gen.4 x16 + 1 x PCIe Gen.3 x4 with FAN, 9~32V DC power input w/o adaptor
Others:
Watchdog Timer (256 steps)
6 x SMA for Wi-Fi and 4G LTE/ 5G/ GPS Antennas
AMI
Intel 13th Gen. Core i9/i7/i5/i3, up to 65W
Intel 12th Gen. Core i9/i7/i5/i3, up to 65W
-
Intel Q670E
2 x 262-pin DDR5 (4800MHz) SO-DIMM Memory, up to 32GB (16GB per slot)
TPM 2.0
1 x Line-out 3.5mm Phone Jack
1 x Mic-in 3.5mm Phone Jack
1 x Power Button with LED
-
1 x DP++ 1.4A, up to 7680 x 4320 @60Hz
-
1 x HDMI 2.0a, up to 4096 x 2160 @60Hz
2 x 2.5GbE LAN RJ-45 (i226LM, LAN1 Support iAMT)
LED Indicators: 1 x M.2 SSD / 1 x 2.5" SATA
1 x 3-pin DC Power Input via Terminal Block
4 x RS-232/422/485 Selectable Default RS-232
4 x USB 3.2 Gen1 Type-A
Default: 1 x M.2 M-key, 2280/2242 (SATA3, PCIe 4.0 x4) for SSD
Option: 2 x 2.5” SATA3 HDD/SSD (Easy-swappable HDD tray), with RAID 0,1
Optional High Speed Expansion I/O:
2 x USB 3.2 Gen1 Type-A
2 x GbE LAN RJ-45 (i210AT/i211AT (from TB-619))
8 x Digital I/O Terminal Block 1x10-pin, 4 x SI, 4 x SO
1 x PCIe x16 + 2 x PCIe x4 or
2 x PCIe x8 + 2 x PCIe x4 (FAN for option)
Note: PCIe Board (include GPU card)
Dimension: L ≦ 195mm, H < 45mm, W ≦ 120mm
1 x M.2 E-key, 2230 for Wi-Fi / Bluetooth
1 x M.2 B-key, 3042/3052 (PCIe 3.0 x1, USB 3.2 Gen.1/ USB2.0) for optional 4G/5G module
1 x NANO SIM slot
Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis
222 x 217 x 186.6
Wall Mount (default) & DIN Rail Back Side (optional)
5.3 kg
Meet CE / FCC Class A
-20~60˚C (for 35W CPU)
-20~50˚C (for 65W CPU),
ambient with air flow (with industrial storage)
10 to 90%@ 40˚C, non-condensing
-40˚C~85˚C
Windows 10 IoT LTSC / Windows 11 IoT / Ubuntu 22.04 (Linux Kernel 5.15)
AVS-532:
Fanless Box PC, 12/13th Gen. Intel Core i3/i5/i7/i9, 2 x DDR5 SO-DIMM slots, 1 x M.2 2280/2242 M-key slot, 2 x 2.5" SSD trays, 4 x COM, 2 x 2.5GbE LAN, 4 x USB 3.2, 1x DP 1.4A, 1 x HDMI 2.0a, 1 x Line-out, 1 x Mic-in, 1 x M.2 2230 E-Key, 1 x M.2 3042/3052 B-key, 1 x PCIe Gen.4 x16 (or 2 x PCIe Gen.4 x8) + 2 x PCIe Gen.3 x4 with FAN , 9~32V DC power input w/o adaptor
AVS-532QL:
Fanless Box PC, 12/13th Gen. Intel Core i3/i5/i7/i9, 2 x DDR5 SO-DIMM slots, 1 x M.2 2280/2242 M-key slot, 2 x 2.5" SSD trays, 4 x COM, 2 x 2.5GbE LAN, 6 x USB 3.2, 1x DP 1.4A, 1 x HDMI 2.0a, 1 x Line-out, 1 x Mic-in, 1 x M.2 2230 E-Key, 1 x M.2 3042/3052 B-key, 2 x GbE LAN, 8-bit DIO, 1 x PCIe Gen.4 x16(or 2 x PCIe Gen.4 x8) + 2 x PCIe Gen.3 x4 with FAN , 9~32V DC power input w/o adaptor
Others:
Watchdog Timer (256 steps)
6 x SMA for Wi-Fi and 4G LTE/ 5G/ GPS Antennas
