7” TFT-LCD
Projected Capacitive Touch
400
NXP i.MX8M Plus Quad, 4 x Cortex-A53 up to 1.6GHz
Onboard 4GB LPDDR4 SDRAM
1 x Pitch 3.5 mm 2 x 5-pin Terminal Block with:
1 x CAN bus 2.0b (CAN_H,CAN_L)
2 x GbE LAN
*LAN1 Support PoE (optional)
1 x Pitch 3.5 mm 2 x 5-pin Terminal Block with:
1 x RS-232(RX,TX,RTS,CTS)/ 2W RS-485(D+,D-), select via jumper
1 x 2W RS-485(D+,D-)
1 x USB 3.0/ USB 2.0, via Vertical USB type A port
1 x USB Download Mode via Micro USB port
Onboard 16GB eMMC Flash
1 x Micro SD slot
20,000
500:1
7” TFT-LCD
400
262K
800 x 480
140 / 140
USB
Around 90%
Projected Capacitive Touch
Engineering Plastic
150 x 204 x 46 mm
IP65 Compliant Front Bezel
Panel Mount, VESA 75 x 75
0.8 kg
CE/FCC Class A, UKCA, RoHS 2.0/ REACH
0~50°C/ -20~60°C (option)
10 to 95% @ 40°C, non- condensing
-30~70°C
Android 11, Yocto Linux 4.0 (Kirkstone)
Wireless Communication:
4G LTE
WiFi/ Bluetooth
